76mm 89mm 102mm DTH Drill Rod

DTH Drill Rod
Diameter: 76mm, 89mm, 102mm, 114mm, 127mm, 140mm;
Length: 1000mm, 1500mm, 2000mm, 3000mm, 5000mm, 6000mm;
Thread: 2 3/8” API REG, 2 7/8” API REG, 3 1/2” API REG, 4 1/2” API REG,2 3/8 API IF, 3 1/2 API IF
Application: DTH drill rod is used for quarrying, water well drilling, mining

Description
Inquiry

Jinzen Drilling have exploring water well rods, exploring water spiral drill rods, outburst-prevention drill rods, DTH drill rods, triangle drill rods, anchor-shank drill rods, extension rods, EU drill rods, RC drill rods, KLEMM drill rods, Ingersoll Rand drill rods etc.

DTH drill rods are widely used in geological exploration, coal mining, water conservancy & hydropower, highway, railway, bridge, building construction etc.

Specification

89mm drill rod (Double buckle)
Diameter(mm)	Length(mm)	Thread model	Weight(kg)	Remarks
89	1500	API 2 3/8" IF	28	Nitrogen treatment Jumping-up
89	2000	API 2 3/8" IF	34
89	3000	API 2 3/8" IF	46
89	6000	API 2 3/8" IF	88
102mm drill rod (Single buckle)
Diameter(mm)	Length(mm)	Thread model	Weight(kg)	Remarks
102	1500	API 2 7/8" IF	37	Nitrogen treatment Jumping-up
102	2000	API 2 7/8" IF	46
102	3000	API 2 7/8" IF	64
102	6000	API 2 7/8" IF	118
102mm drill pipe (Double buckle)
Diameter(mm)	Length(mm)	Thread model	Weight(kg)	Remarks
102	1500	API 2 7/8" IF	38	Nitrogen treatment Jumping-up
102	2000	API 2 7/8" IF	47
102	3000	API 2 7/8" IF	65
102	6000	API 2 7/8" IF	119
